@Resource注解注入源码解析

doMore 372 2023-10-25

源码解析

javax.annotation.Resource 归属 Java 源码包,主流的服务容器都支持使用它进行依赖注入。

再次进行 spring 源码解析,进一步加深理解。

  1. @Resource 解析入口 org.springframework.context.annotation.CommonAnnotationBeanPostProcessor#postProcessProperties

@Override
public PropertyValues postProcessProperties(PropertyValues pvs, Object bean, String beanName) {
	// 查询注入点
    InjectionMetadata metadata = findResourceMetadata(beanName, bean.getClass(), pvs);
    try {
		// 完成注入
       metadata.inject(bean, beanName, pvs);
    }
    catch (Throwable ex) {
       throw new BeanCreationException(beanName, "Injection of resource dependencies failed", ex);
    }
    return pvs;
}

  1. 查询注入点 org.springframework.context.annotation.CommonAnnotationBeanPostProcessor#findResourceMetadata
private InjectionMetadata findResourceMetadata(String beanName, Class<?> clazz, @Nullable PropertyValues pvs) {
    // Fall back to class name as cache key, for backwards compatibility with custom callers.
String cacheKey = (StringUtils.hasLength(beanName) ? beanName : clazz.getName());
    // Quick check on the concurrent map first, with minimal locking.
// 先查看缓存是否存在
    InjectionMetadata metadata = this.injectionMetadataCache.get(cacheKey);
    // 判断是否为空 或者 是否是 Class 对象
    if (InjectionMetadata.needsRefresh(metadata, clazz)) {
        synchronized (this.injectionMetadataCache) {
            metadata = this.injectionMetadataCache.get(cacheKey);
            if (InjectionMetadata.needsRefresh(metadata, clazz)) {
                if (metadata != null) {
                    metadata.clear(pvs);
                }
                // 查询并构建 注入点
                metadata = buildResourceMetadata(clazz);
                // 加入缓存
                this.injectionMetadataCache.put(cacheKey, metadata);
            }
        }
    }
    return metadata;
}

  1. 真正查询并构建注入点方法 org.springframework.context.annotation.CommonAnnotationBeanPostProcessor#buildResourceMetadata

private InjectionMetadata buildResourceMetadata(Class<?> clazz) {
    if (!AnnotationUtils.isCandidateClass(clazz, resourceAnnotationTypes)) {
       return InjectionMetadata.EMPTY;
    }

    List<InjectionMetadata.InjectedElement> elements = new ArrayList<>();
    Class<?> targetClass = clazz;

    do {
       final List<InjectionMetadata.InjectedElement> currElements = new ArrayList<>();
		// 属性 依据不同的注解 解析 并构建 InjectedElement 对象
       ReflectionUtils.doWithLocalFields(targetClass, field -> {
          if (webServiceRefClass != null && field.isAnnotationPresent(webServiceRefClass)) {
             if (Modifier.isStatic(field.getModifiers())) {
                throw new IllegalStateException("@WebServiceRef annotation is not supported on static fields");
             }
             currElements.add(new WebServiceRefElement(field, field, null));
          }
          else if (ejbClass != null && field.isAnnotationPresent(ejbClass)) {
             if (Modifier.isStatic(field.getModifiers())) {
                throw new IllegalStateException("@EJB annotation is not supported on static fields");
             }
             currElements.add(new EjbRefElement(field, field, null));
          }
          else if (field.isAnnotationPresent(Resource.class)) {
             if (Modifier.isStatic(field.getModifiers())) {
                throw new IllegalStateException("@Resource annotation is not supported on static fields");
             }
             if (!this.ignoredResourceTypes.contains(field.getType().getName())) {
                currElements.add(new ResourceElement(field, field, null));
             }
          }
       });

		// 方法 依据不同的注解 解析 并构建 InjectedElement 对象
       ReflectionUtils.doWithLocalMethods(targetClass, method -> {
          Method bridgedMethod = BridgeMethodResolver.findBridgedMethod(method);
          if (!BridgeMethodResolver.isVisibilityBridgeMethodPair(method, bridgedMethod)) {
             return;
          }
          if (method.equals(ClassUtils.getMostSpecificMethod(method, clazz))) {
             if (webServiceRefClass != null && bridgedMethod.isAnnotationPresent(webServiceRefClass)) {
                if (Modifier.isStatic(method.getModifiers())) {
                   throw new IllegalStateException("@WebServiceRef annotation is not supported on static methods");
                }
                if (method.getParameterCount() != 1) {
                   throw new IllegalStateException("@WebServiceRef annotation requires a single-arg method: " + method);
                }
                PropertyDescriptor pd = BeanUtils.findPropertyForMethod(bridgedMethod, clazz);
                currElements.add(new WebServiceRefElement(method, bridgedMethod, pd));
             }
             else if (ejbClass != null && bridgedMethod.isAnnotationPresent(ejbClass)) {
                if (Modifier.isStatic(method.getModifiers())) {
                   throw new IllegalStateException("@EJB annotation is not supported on static methods");
                }
                if (method.getParameterCount() != 1) {
                   throw new IllegalStateException("@EJB annotation requires a single-arg method: " + method);
                }
                PropertyDescriptor pd = BeanUtils.findPropertyForMethod(bridgedMethod, clazz);
                currElements.add(new EjbRefElement(method, bridgedMethod, pd));
             }
             else if (bridgedMethod.isAnnotationPresent(Resource.class)) {
                if (Modifier.isStatic(method.getModifiers())) {
                   throw new IllegalStateException("@Resource annotation is not supported on static methods");
                }
                Class<?>[] paramTypes = method.getParameterTypes();
                if (paramTypes.length != 1) {
                   throw new IllegalStateException("@Resource annotation requires a single-arg method: " + method);
                }
                if (!this.ignoredResourceTypes.contains(paramTypes[0].getName())) {
                   PropertyDescriptor pd = BeanUtils.findPropertyForMethod(bridgedMethod, clazz);
                   currElements.add(new ResourceElement(method, bridgedMethod, pd));
                }
             }
          }
       });

       elements.addAll(0, currElements);
       targetClass = targetClass.getSuperclass();
    }
    while (targetClass != null && targetClass != Object.class);

    return InjectionMetadata.forElements(elements, clazz);
}


此处只关注 对于 @Resource 注解的解析。

  1. 构建 ResourceElement

public ResourceElement(Member member, AnnotatedElement ae, @Nullable PropertyDescriptor pd) {
    super(member, pd);
    Resource resource = ae.getAnnotation(Resource.class);
    String resourceName = resource.name();
    Class<?> resourceType = resource.type();
    // 查看 Resource 注解中是否指定了 name
    this.isDefaultName = !StringUtils.hasLength(resourceName);
    if (this.isDefaultName) {
       resourceName = this.member.getName();
       // 判断 是否是 标注在 方法上
       if (this.member instanceof Method && resourceName.startsWith("set") && resourceName.length() > 3) {
          resourceName = Introspector.decapitalize(resourceName.substring(3));
       }
    }
    else if (embeddedValueResolver != null) {
       resourceName = embeddedValueResolver.resolveStringValue(resourceName);
    }
    if (Object.class != resourceType) {
       checkResourceType(resourceType);
    }
    else {
       // No resource type specified... check field/method.
       resourceType = getResourceType();
    }
    this.name = (resourceName != null ? resourceName : "");
    this.lookupType = resourceType;
    String lookupValue = resource.lookup();
    this.mappedName = (StringUtils.hasLength(lookupValue) ? lookupValue : resource.mappedName());
    Lazy lazy = ae.getAnnotation(Lazy.class);
    this.lazyLookup = (lazy != null && lazy.value());
}

  1. 构建完成 注入的元素之后,再看 执行注入的方法 org.springframework.beans.factory.annotation.InjectionMetadata#inject

public void inject(Object target, @Nullable String beanName, @Nullable PropertyValues pvs) throws Throwable {
    Collection<InjectedElement> checkedElements = this.checkedElements;
    Collection<InjectedElement> elementsToIterate =
          (checkedElements != null ? checkedElements : this.injectedElements);
    if (!elementsToIterate.isEmpty()) {
       for (InjectedElement element : elementsToIterate) {
       // 调用上一步 构建的元素的 注入方法
          element.inject(target, beanName, pvs);
       }
    }
}


protected void inject(Object target, @Nullable String requestingBeanName, @Nullable PropertyValues pvs)
       throws Throwable {
	// 判断是否是属性,如果是,则反射赋值
    if (this.isField) {
       Field field = (Field) this.member;
       ReflectionUtils.makeAccessible(field);
       field.set(target, getResourceToInject(target, requestingBeanName));
    }
    else {
    // 检查是否需要跳过该属性,并且 标记已经处理
       if (checkPropertySkipping(pvs)) {
          return;
       }
       try {
          // 执行方法进行赋值
          Method method = (Method) this.member;
          ReflectionUtils.makeAccessible(method);
          method.invoke(target, getResourceToInject(target, requestingBeanName));
       }
       catch (InvocationTargetException ex) {
          throw ex.getTargetException();
       }
    }
}

  1. 重点关注 org.springframework.context.annotation.CommonAnnotationBeanPostProcessor.ResourceElement#getResourceToInject

此处不进行懒加载分析


@Override
protected Object getResourceToInject(Object target, @Nullable String requestingBeanName) {
    return (this.lazyLookup ? buildLazyResourceProxy(this, requestingBeanName) :
          getResource(this, requestingBeanName));
}

// org.springframework.context.annotation.CommonAnnotationBeanPostProcessor#getResource
protected Object getResource(LookupElement element, @Nullable String requestingBeanName)
       throws NoSuchBeanDefinitionException {

    // JNDI lookup to perform?
    String jndiName = null;
    if (StringUtils.hasLength(element.mappedName)) {
       jndiName = element.mappedName;
    }
    else if (this.alwaysUseJndiLookup) {
       jndiName = element.name;
    }
    if (jndiName != null) {
       if (this.jndiFactory == null) {
          throw new NoSuchBeanDefinitionException(element.lookupType,
                "No JNDI factory configured - specify the 'jndiFactory' property");
       }
       return this.jndiFactory.getBean(jndiName, element.lookupType);
    }

    // Regular resource autowiring
    if (this.resourceFactory == null) {
       throw new NoSuchBeanDefinitionException(element.lookupType,
             "No resource factory configured - specify the 'resourceFactory' property");
    }
    // 最后会走到这里
    // this.resourceFactory 默认情况下为  org.springframework.beans.factory.support.DefaultListableBeanFactory
    return autowireResource(this.resourceFactory, element, requestingBeanName);
}



// org.springframework.context.annotation.CommonAnnotationBeanPostProcessor#autowireResource
protected Object autowireResource(BeanFactory factory, LookupElement element, @Nullable String requestingBeanName)
       throws NoSuchBeanDefinitionException {

    Object resource;
    Set<String> autowiredBeanNames;
    String name = element.name;

    if (factory instanceof AutowireCapableBeanFactory) {
       AutowireCapableBeanFactory beanFactory = (AutowireCapableBeanFactory) factory;
       DependencyDescriptor descriptor = element.getDependencyDescriptor();
       // 判断 是否通过类型匹配,名称匹配,是否已经创建
       if (this.fallbackToDefaultTypeMatch && element.isDefaultName && !factory.containsBean(name)) {
          // 该类型的所有名称
          autowiredBeanNames = new LinkedHashSet<>();
        // 解析获取 符合注入条件的对象
        // 注解中无特殊指定,会走到这里
          resource = beanFactory.resolveDependency(descriptor, requestingBeanName, autowiredBeanNames, null);
          if (resource == null) {
             throw new NoSuchBeanDefinitionException(element.getLookupType(), "No resolvable resource object");
          }
       }
       else {
       // 如果在 @Resource 注解中指定了 name,则只会根据 名称注入
          resource = beanFactory.resolveBeanByName(name, descriptor);
          autowiredBeanNames = Collections.singleton(name);
       }
    }
    else {
       resource = factory.getBean(name, element.lookupType);
       autowiredBeanNames = Collections.singleton(name);
    }

    if (factory instanceof ConfigurableBeanFactory) {
       ConfigurableBeanFactory beanFactory = (ConfigurableBeanFactory) factory;
       for (String autowiredBeanName : autowiredBeanNames) {
          if (requestingBeanName != null && beanFactory.containsBean(autowiredBeanName)) {
             beanFactory.registerDependentBean(autowiredBeanName, requestingBeanName);
          }
       }
    }

    return resource;
}


  1. 获取符合注入条件的对象 org.springframework.beans.factory.support.DefaultListableBeanFactory#resolveDependency

public Object resolveDependency(DependencyDescriptor descriptor, @Nullable String requestingBeanName,
       @Nullable Set<String> autowiredBeanNames, @Nullable TypeConverter typeConverter) throws BeansException {

    descriptor.initParameterNameDiscovery(getParameterNameDiscoverer());
    if (Optional.class == descriptor.getDependencyType()) {
       return createOptionalDependency(descriptor, requestingBeanName);
    }
    else if (ObjectFactory.class == descriptor.getDependencyType() ||
          ObjectProvider.class == descriptor.getDependencyType()) {
       return new DependencyObjectProvider(descriptor, requestingBeanName);
    }
    else if (javaxInjectProviderClass == descriptor.getDependencyType()) {
       return new Jsr330Factory().createDependencyProvider(descriptor, requestingBeanName);
    }
    else {
       Object result = getAutowireCandidateResolver().getLazyResolutionProxyIfNecessary(
             descriptor, requestingBeanName);
       if (result == null) {
       // 执行真正的方法
          result = doResolveDependency(descriptor, requestingBeanName, autowiredBeanNames, typeConverter);
       }
       return result;
    }
}




// org.springframework.beans.factory.support.DefaultListableBeanFactory#doResolveDependency
@Nullable
public Object doResolveDependency(DependencyDescriptor descriptor, @Nullable String beanName,
       @Nullable Set<String> autowiredBeanNames, @Nullable TypeConverter typeConverter) throws BeansException {

    InjectionPoint previousInjectionPoint = ConstructorResolver.setCurrentInjectionPoint(descriptor);
    try {
       Object shortcut = descriptor.resolveShortcut(this);
       if (shortcut != null) {
          return shortcut;
       }

       Class<?> type = descriptor.getDependencyType();
       Object value = getAutowireCandidateResolver().getSuggestedValue(descriptor);
       if (value != null) {
          if (value instanceof String) {
             String strVal = resolveEmbeddedValue((String) value);
             BeanDefinition bd = (beanName != null && containsBean(beanName) ?
                   getMergedBeanDefinition(beanName) : null);
             value = evaluateBeanDefinitionString(strVal, bd);
          }
          TypeConverter converter = (typeConverter != null ? typeConverter : getTypeConverter());
          try {
             return converter.convertIfNecessary(value, type, descriptor.getTypeDescriptor());
          }
          catch (UnsupportedOperationException ex) {
             // A custom TypeConverter which does not support TypeDescriptor resolution...
             return (descriptor.getField() != null ?
                   converter.convertIfNecessary(value, type, descriptor.getField()) :
                   converter.convertIfNecessary(value, type, descriptor.getMethodParameter()));
          }
       }

       Object multipleBeans = resolveMultipleBeans(descriptor, beanName, autowiredBeanNames, typeConverter);
       if (multipleBeans != null) {
          return multipleBeans;
       }

		// 根据 类型和 名称查找符合条件的对象
       Map<String, Object> matchingBeans = findAutowireCandidates(beanName, type, descriptor);
       if (matchingBeans.isEmpty()) {
          if (isRequired(descriptor)) {
             raiseNoMatchingBeanFound(type, descriptor.getResolvableType(), descriptor);
          }
          return null;
       }

       String autowiredBeanName;
       Object instanceCandidate;
		// 查找到多个符合条件的 进行下一步判断  如 @Primary 和 优先级 @Order 等注解
       if (matchingBeans.size() > 1) {
          autowiredBeanName = determineAutowireCandidate(matchingBeans, descriptor);
          if (autowiredBeanName == null) {
             if (isRequired(descriptor) || !indicatesMultipleBeans(type)) {
                return descriptor.resolveNotUnique(descriptor.getResolvableType(), matchingBeans);
             }
             // 无法确定明确对象的返回 null
             else {
                // In case of an optional Collection/Map, silently ignore a non-unique case:
                // possibly it was meant to be an empty collection of multiple regular beans                // (before 4.3 in particular when we didn't even look for collection beans).
                 return null;
             }
          }
          instanceCandidate = matchingBeans.get(autowiredBeanName);
       }
       else {
       // 只有 一个符合的 记录名称 和 对象
          // We have exactly one match.
          Map.Entry<String, Object> entry = matchingBeans.entrySet().iterator().next();
          autowiredBeanName = entry.getKey();
          instanceCandidate = entry.getValue();
       }

       if (autowiredBeanNames != null) {
          autowiredBeanNames.add(autowiredBeanName);
       }
       if (instanceCandidate instanceof Class) {
          instanceCandidate = descriptor.resolveCandidate(autowiredBeanName, type, this);
       }
       Object result = instanceCandidate;
       if (result instanceof NullBean) {
          if (isRequired(descriptor)) {
             raiseNoMatchingBeanFound(type, descriptor.getResolvableType(), descriptor);
          }
          result = null;
       }
       if (!ClassUtils.isAssignableValue(type, result)) {
          throw new BeanNotOfRequiredTypeException(autowiredBeanName, type, instanceCandidate.getClass());
       }
       return result;
    }
    finally {
       ConstructorResolver.setCurrentInjectionPoint(previousInjectionPoint);
    }
}


  1. 查找符合条件的对象 org.springframework.beans.factory.support.DefaultListableBeanFactory#findAutowireCandidates

protected Map<String, Object> findAutowireCandidates(
       @Nullable String beanName, Class<?> requiredType, DependencyDescriptor descriptor) {
  // 获取该类型 所有的名称
    String[] candidateNames = BeanFactoryUtils.beanNamesForTypeIncludingAncestors(
          this, requiredType, true, descriptor.isEager());
    Map<String, Object> result = CollectionUtils.newLinkedHashMap(candidateNames.length);
    for (Map.Entry<Class<?>, Object> classObjectEntry : this.resolvableDependencies.entrySet()) {
       Class<?> autowiringType = classObjectEntry.getKey();
       if (autowiringType.isAssignableFrom(requiredType)) {
          Object autowiringValue = classObjectEntry.getValue();
          autowiringValue = AutowireUtils.resolveAutowiringValue(autowiringValue, requiredType);
          if (requiredType.isInstance(autowiringValue)) {
             result.put(ObjectUtils.identityToString(autowiringValue), autowiringValue);
             break;
          }
       }
    }
    // 判断是否是自引用 是否符合
    // isAutowireCandidate  ->  Determine whether the specified bean definition qualifies as an autowire candidate, to be injected into other beans which declare a dependency of matching type.   确定指定的bean定义是否有资格作为自动候选对象,以注入声明匹配类型依赖的其他bean中。
    for (String candidate : candidateNames) {
       if (!isSelfReference(beanName, candidate) && isAutowireCandidate(candidate, descriptor)) {
          addCandidateEntry(result, candidate, descriptor, requiredType);
       }
    }
    // 第一轮没有找到符合的对象,在进行额外的处理
    if (result.isEmpty()) {
       boolean multiple = indicatesMultipleBeans(requiredType);
       // Consider fallback matches if the first pass failed to find anything...
       DependencyDescriptor fallbackDescriptor = descriptor.forFallbackMatch();
       for (String candidate : candidateNames) {
          if (!isSelfReference(beanName, candidate) && isAutowireCandidate(candidate, fallbackDescriptor) &&
                (!multiple || getAutowireCandidateResolver().hasQualifier(descriptor))) {
             addCandidateEntry(result, candidate, descriptor, requiredType);
          }
       }
       if (result.isEmpty() && !multiple) {
          // Consider self references as a final pass...
          // but in the case of a dependency collection, not the very same bean itself.          for (String candidate : candidateNames) {
             if (isSelfReference(beanName, candidate) &&
                   (!(descriptor instanceof MultiElementDescriptor) || !beanName.equals(candidate)) &&
                   isAutowireCandidate(candidate, fallbackDescriptor)) {
                addCandidateEntry(result, candidate, descriptor, requiredType);
             }
          }
       }
    }
    return result;
}


总结

  1. @Resource 注解中指定了 name ,只会根据名称注入,找不到就会报错。
  2. @Resource 注解中没有指定 name,则会根据类型、名称 去找符合条件的对象进行注入。
